27 Jul Badger 4i
Badger 4i
Give your family a home in the wild, with Australia’s most reliable off-road caravan, adapted for Australian conditions. Wherever you set up camp, it will feel like supreme luxury.
The ‘go-big-or-go-home’ Badger 4 is available in two versions. In the new Ratel 4i, the double bed converts to a table with two seats. See below for detailed illustrations.
- Set up camp in under 15 minutes.
- Sleeps 4 adults.
- double bed converts to table with two seats
- 1140kg dry weight
- 3CR12 Stainless steel body and chassis with a 1 year warranty.
- GVM 1800 kg
- Departure angle of 22°
- Comes standard with the fuss-free Bush Wing® awning including complete set of sides, and spacious kitchen layout, additional fridge drawer with loads of storage space, shower wing under awning and lots more.
GENERAL SPECIFICATIONS
- Dry Weight – TARE: 1140kg
- Total Length (Spare wheel incl): 5440mm
- Total Height to roof top: 2150mm
- Total Height to top of Bush Wing (depending on tyre size): 2250mm
- Head room inside: 1980mm
- Total Width (excl Bush Wing & Shower Wing): 1980mm
- Ground Clearance (axle): 350mm
- Departure angle: 22°
- Solid beam axle with leaf springs and shock absorbers: 1800kg
- GVM: 1800kg
- Loading Capacity: 660kg
- Queen front beds: 1
- Inside bed (1200x1900mm, converts to table with two seats): 1
- Sleeps: 4 Adults
- Stainless Steel Body and Chassis
- Aluminium interior and doors
- Micro Dotted (also known as Data Dot) for additional security.
- 1 Year Guarantee (ex factory) on material and workmanship, other items as per manufacturer’s guarantees
STANDARD FEATURES
- Bush Wing awning 90° x 270° x 1
- Sides for Bush Wing (2x doors) x 6
- Draft skirt x 2
- Mosquito net at door x 2
- 16" Wheels, 6 stud, 139mm PCD, black mags (spare wheel with steel rim)
- Kitchen with stainless steel working table x 1
- Stabilizers/Jacks/High lift jacks x 2
- Wheel spanner, lockable spare wheel x 1
- Double cupboards for clothes with canvassing & zips x 20
- Mattresses: 1 x Queen & 1 x (1200x1900mm
- Inside bed with window & mosquito net x 1
- Front bed with tent
- Dual entry doors x 2
- Shower cubicle x 1
- Inside floor carpet x 1
- Heavy duty jockey wheel x 1
- Jockey wheel out of the way bracket x 1
- Aluminium chequered nose boxes x 1
- Jerry can holder between nose boxes x 1
- Aluminium wood racks on top of nose boxes x 2
- Multi round LED x 1
- LED Lights: 4 x kitchen, 1 x bed tent, 1 x entrance door, 1 x gas hot water door
- Outside DUAL Touch LED Lights: x 4
- Merit / Hella points 12V output x 3
- Anderson Fridge points 12V 50A x 1
- 240V Inlet caravan plug x 1
- 240V plug (3 point) outside at kitchen x 3
- 240V plug (2 point) inside (built in breaker) x 1
- 240V plug (3 point) inside (built in breaker) x 1
- Intelligent Charging system, monitor and Bush Lapa power panel with USB plugs x 1
- Charging system from vehicle (Anderson plug on A-frame) x 1
- Mudflaps x 2
- Mudflap stone protectors for chassis x 1
- Crockery set in canvas holder (for six) x 1
- Fire extinguisher x 1
- Wash basin inside with mixer tap x 1
- Double wash basin with aluminium frame (removable) x 1
- Heavy duty aluminium kitchen drawer system x 1
- Gas cylinder bracket in nose box x 2
- 150 Litre stainless steel water tank under chassis with automatic pump, filler cap, tap and drain plug x 1
- Hot and cold water taps on rear for wash basins x 1 each
- Hot and cold water mixer at fridge drawer for wash basins & cooking x 1
- Spare wheel cover x 1
- Transport included to Bush Lapa branches & agents x 1
OPTIONAL EXTRAS
- Solar Panel 140W with controller and aluminium roof rack
- National Luna 90L fridge/freezer
- 2 x 130AH Deep cycle batteries
- Bearing kit
- Mag Wheels 17” or 18”
- 6 Litre/min gas hot water with direct connection to rear tap
- Shower Wing
- Aluminium Toolbox between Nose boxes
- Gas cylinders 4kg (filled)
- 1200mm x 600mm Loose standing aluminium table with fold in legs and PVC bag
- Jerry cans x 2
- 240V Caravan extension lead for mains 10m x 1
- 2 Burner Dometic glass top gas cooker fixed in stainless steel stand x 1
- Other optional items available – please contact us for details
